Sector 76



Sector 76 Information

For full data release notes see: DRN107. For a list of TIC IDs with noted issues, see this list.

Sector Summary

  • Sector dates: February 27 to March 25 2024
  • Pointing: Northern hemisphere
  • Days of Science Data Collection: 26.46
  • Days of Paused Data Collection: 0.63



    • Spacecraft Pointing (deg)

    RA dec roll
    Spacecraft 253.53 66.84 276.64
    Camera 1 196.64 45.81 55.91
    Camera 2 226.62 62.86 31.1
    Camera 3 283.2 65.34 159.42
    Camera 4 319.88 50.4 127.8



    Orbit Summary

    Orbits Dates (UTC)

    Start - End

    		 Cadence #

    Start - End

    		 Momentum dumps
    159a 2024-02-27 - 2024-03-04 1540971 - 1545572 1
    159b 2024-03-04 - 2024-03-11 1545724 - 1550830 1
    160a 2024-03-12 - 2024-03-18 1550981 - 1555857 1
    160b 2024-03-19 - 2024-03-25 1556009 - 1560472 1



    Sector Notes

    Noted Issue Description
    Spacecraft pointing: The pointing in Sector 76 was set at +83.5 degrees in ecliptic latitude so that Camera 3 points near the North Ecliptic Pole. Camera 4 was used for guiding in both orbits.
    Scattered light: In Sector 76, the Earth introduces scattered light signals in the beginning of Orbit 159a and 160a, and the Moon impacts Camera 1 near the middle of Orbit 160b.
