Sector 75



Sector 75 Information

For full data release notes see: DRN106. For a list of TIC IDs with noted issues, see this list.

Sector Summary

  • Sector dates: January 30 to February 26 2024
  • Pointing: Northern hemisphere
  • Days of Science Data Collection: 27.07
  • Days of Paused Data Collection: 0.63



    • Spacecraft Pointing (deg)

    RA dec roll
    Spacecraft 254.93 69.94 247.49
    Camera 1 171.87 56.84 54.6
    Camera 2 218.55 71.1 11.91
    Camera 3 280.01 63.06 134.38
    Camera 4 302.93 43.06 115.7



    Orbit Summary

    Orbits Dates (UTC)

    Start - End

    		 Cadence #

    Start - End

    		 Momentum dumps
    157a 2024-01-30 - 2024-02-05 1520874 - 1525480 1
    157b 2024-02-05 - 2024-02-13 1525631 - 1530792 1
    158a 2024-02-13 - 2024-02-19 1530944 - 1535520 1
    158b 2024-02-19 - 2024-02-26 1535671 - 1540820 1



    Sector Notes

    Noted Issue Description
    Spacecraft pointing: The pointing in Sector 75 was set at +83.5 degrees in ecliptic latitude so that Camera 3 points near the North Ecliptic Pole. Camera 4 was used for guiding in Orbits 157a and 158a. Cameras 1 and 4 were used in Orbits 157b and 158b.
    Scattered light: In Sector 75, the Earth introduces scattered light signals after the beginning of each orbit, and the Moon impacts Camera 1 near the middle of Orbit 158.
