Sector 72 Information

For full data release notes see: DRN102. For a list of TIC IDs with noted issues, see this list.

Sector Summary

  • Sector dates: November 11 to December 7 2023
  • Pointing: Ecliptic
  • Days of Science Data Collection: 24.8
  • Days of Paused Data Collection: 0.63



    • Spacecraft Pointing (deg)

    RA dec roll
    Spacecraft 133.76 16.65 254.03
    Camera 1 95.97 22.75 357.22
    Camera 2 121.51 19.58 347.85
    Camera 3 145.6 13.03 160.99
    Camera 4 168.29 4.41 157.49



    Orbit Summary

    Orbits Dates (UTC)

    Start - End

    		 Cadence #

    Start - End

    		 Momentum dumps
    151a 2023-11-11 - 2023-11-17 1463561 - 1468002 1
    151b 2023-11-18 - 2023-11-24 1468154 - 1472792 1
    152a 2023-11-24 - 2023-11-30 1472944 - 1477347 1
    152b 2023-12-01 - 2023-12-07 1477499 - 1481852 1



    Sector Notes

    Noted Issue Description
    Corrupted data: One FFI from Camera 2 in orbit 151 was corrupted prior to downlink from the spacecraft and could not be recovered. The FFIINDEX number is 878254, and no FFI file for Camera 2 was produced for this cadence.
    Spacecraft pointing: The pointing in Sector 72 was set at -0.7 degrees in ecliptic latitude with the cameras aligned parallel to the ecliptic plane. Camera 1 was used for guiding in Orbit 151a and Cameras 1 and 4 were used in Orbit 151b. Camera 1 was used for guiding in Orbit 152a and Cameras 1 and 4 in 152b.
    Scattered light: In Sector 72, the Earth introduces scattered light signals at the beginning of each orbit, and the Moon impacts Camera 4 at the end of Orbit 152.
