Sector 23



Sector 23 Information

For full data release notes see: DRN32. For a list of TIC IDs with noted issues, see this list.

Sector Summary

  • Sector dates: March 19 to April 15 2020
  • Pointing: Northern hemispher
  • Days of Science Data Collection: 25.81
  • Days of Paused Data Collection: >0.96



    • Spacecraft Pointing (deg)

    RA dec roll
    Spacecraft 217.29 43.81 327.42
    Camera 1 198.43 11.69 66.62
    Camera 2 209.58 33.41 62.26
    Camera 3 228.13 53.47 229.25
    Camera 4 270.0 66.56 192.35



    Orbit Summary

    Orbits Dates (UTC)

    Start - End

    		 Cadence #

    Start - End

    		 Momentum dumps
    53 2020-03-19 - 2020-04-01 504464 - 513659 1
    54 2020-04-02 - 2020-04-15 514351 - 523742 1



    Sector Notes

    Noted Issue Description
    Instrument issues The spacecraft passed through the shadow of Earth from approximately TJD 1940.38 – 1940.48. The instrument was not turned off, and other than the instrument heaters turning on resulting in a minor pointing offset, there is no indication that science quality was affected.
    Spacecraft pointing In orbit 1 of Sector 23, anomalously high pointing jitter was observed for about 1.5 days before the momentum dump starting at ∼ TJD 1936.15. The peak-to-peak amplitude of the jitter is less than 1.5 arcseconds on 2 minute timescales.
    Scattered light Camera 1 suffered from strong scattered light signals at the beginning of orbit 53 and orbit 54, and so Camera 4 alone was used for guiding during this sector. The Earth is a significant source of scattered light at the start of both orbits. The Moon also passes close to the field of view of Camera 1 during orbit 54.
